| Keyboard | Keyboard | Responsive Hammer III (RHIII) action with Let-Off |
|---|
| | 88 weighted keys with Ivory Touch key surfaces |
|---|
| Sound Source | Sound Source | Harmonic Imaging™ XL (HI-XL) |
|---|
| | 88-key piano sampling |
|---|
| Internal Sounds | Internal Sounds | 38 sounds (PIANO x 10, E.PIANO x 6, ORGAN x 5, HARPSI/MALLETS x 4, STRINGS/CHOIR x 8, BASS x 5) |
|---|
| Polyphony | Polyphony | max. 256 notes |
|---|
| Keyboard Modes | Keyboard Modes | Dual Mode, Split Mode, Four Hands Mode (Volume/Balance adjustable) |
|---|
| Reverb | Type | Room, Lounge, Small Hall, Concert Hall, Live Hall, Cathedral |
|---|
| Parameters | Reverb Depth, Reverb Time |
|---|
| Effects | Type | Mono Delay, Ping Delay, Triple Delay, Chorus, Classic Chorus, Ensemble, Tremolo, Classic Tremolo, Vibrato Tremolo, Auto Pan, Classic Auto Pan, Phaser, Classic Phaser, Compressor, Rotary 1, Rotary2 |
|---|
| Parameters | Dry/Wet, Time, Speed, Feedback, HighDamp, Depth – Parameters dependent on effect |
|---|
| Amp Simulator | Type | S.Case I, S.Case II, L.Cabinet |
|---|
| Parameters | Drive, Level, EQ Low, EQ High |
|---|
| Virtual Technician | Touch Curve | Light 1/2/3/4, Normal, Heavy 1/2/3/4, Off (Constant), User Touch Curve |
|---|
| Voicing | Normal, Mellow 1, Mellow 2 , Dynamic, Bright 1, Bright 2, User Voicing |
|---|
| Resonance, Noise & Effects | Damper Resonance, Damper Noise, String Resonance, Undamped String Resonance, Cabinet Resonance, Key-off Effect, Fall-back Noise, Hammer Noise, Topboard Simulation, Decay Time, Release Time |
|---|
| Temperament & Tuning | Equal, Pure Major, Pure Minor, Pythagorean, Meantone, Werckmeister, Kirnberger, User Temperament, Temperament Key, Stretch Tuning, User Tuning |
|---|
| Others | Hammer Delay, Minimum Touch, User Key Volume, Half-Pedal Adjust, Soft Pedal Depth |
|---|
| Internal Recorder | Internal Recorder | 10 song, 2 track recorder – approximately 90,000 note memory capacity |
|---|
| USB Functions | Playback | MP3, WAV, SMF |
|---|
| Record | MP3, WAV |
|---|
| Others | Overdubbing, Convert Song to Audio, Load Internal Song, Save Internal Song, Save SMF Song, Load Registration, Save Registration, Load Startup Setting, Save Startup Setting, Rename File, Delete File, Format USB |
|---|
| Metronome | Metronome | 1/4, 2/4, 3/4, 4/4, 5/4, 3/8, 6/8, 7/8, 9/8, 12/8 (Volume/Tempo adjustable) |
|---|
| Rhythm Section | Styles | 100 rhythms (x 2 variations), 4-part accompaniment, 100 preset chord sequences |
|---|
| Settings | Rhythm Volume, Auto Fill-in, One Finger Ad-lib, ACC Mode, Preset Chord, Rhythm Parts Select |
|---|
| Demo Songs | Demo Songs | Main demo song, Rhythm Section demo song, 25 sound demo songs |
|---|
| Registrations | Registrations | 28 memories (7 x 4) |
|---|
| Other Settings & Functions | Other Settings & Functions | Key/Song Transpose, Tone Control (incl. Brilliance, UserEQ), Wall EQ, Speaker Volume, Low Volume Balance, Phones Volume, Line Out Volume, Audio Recorder Gain, Tuning, Damper Hold, GFP-3 Mode, Four Hands, Startup Setting, Factory Reset, Auto Power Off, Auto Display Off, Lower Octave Shift, Lower Pedal On/Off, Split Balance, Layer Octave Shift, Layer Dynamics, Dual Balance, SHS Mode, Phones Type, MIDI Channel, Send PGM#, Local Control, Transmit PGM#, Multi-timbral Mode, Channel Mute, Bluetooth Audio, Bluetooth Audio Volume, Bluetooth MIDI, Speakers On/Off |
|---|
| Display | Display | 128 x 64 pixel OLED |
|---|
| Pedal | Pedal | F-10H damper pedal (with half-pedal support) |
|---|
| Bluetooth | Bluetooth | Bluetooth (Ver. 4.1; GATT compatible) |
|---|
| Connectors | Connectors | LINE IN (1/8" STEREO), LINE OUT (1/4" L/MONO, R [unbalanced]), Headphones x 2 (1/4”, 1/8”), MIDI (IN/OUT), USB to Host, USB to Device, DAMPER (for F-10H), DAMPER/SOFT/SOSTENUTO (for GFP-3/F-302) |
|---|
| Speaker System | Speakers | (8 x 12 cm) x 2 |
|---|
| Output Power | 20 W x 2 |
|---|
| Power Consumption | Power Consumption | 18 W (PS-154 AC adaptor) |
|---|
| Dimensions | Dimensions (Not including music rest) | 1340 (W) x 375 (D) x 145 (H) mm |
|---|
