General |
|
|
|
Master Level Control |
|
|
Wooden Pitch Stick |
|
|
Modulation Wheel |
|
|
512 Programs |
8 Banks with 8 Pages each. Each Page has 8 Program locations. |
|
Preset Library |
with Organ, Piano and Synth Presets including effects. 2x64 Organ Preset locations, 2x64 Piano Preset locations, 8x64 Synth Preset locations |
|
Live Programs |
8 |
|
Individual Layer Scene Setups |
2 |
|
3 Morph sources |
Modulation Wheel (also controllable by Swell pedal), Control Pedal, Aftertouch |
|
Output routing options |
Stereo and Mono |
|
Programmable Transpose |
+/- 6 semitones |
|
Master Clock functionality |
Manual, external and tap-tempo rate control |
|
Clock source |
Internal and MIDI |
|
MIDI over USB functionality |
Yes |
|
Level control |
Yes |
|
Aftertouch |
Yes |
|
Split Points |
Up to 3 Split Points (4 Keyboard Zones) with visual LED indication between zones |
|
3 Split Point width (crossfade) options |
Lrg, Sml or Off |
Organ Section |
Nord C2D B3 Tone wheel Organ simulation |
|
|
Vox Continental and Farfisa models |
|
|
2 Digital Pipe Organ models |
|
|
B3 Bass mode |
|
|
Physical Drawbars with LED graphs |
|
|
Preset or Drawbar Live mode |
|
|
Percussion controls |
|
|
Vibrato / Chorus control |
|
|
2 Layers (2-Part Multitimbral) |
|
Piano Section |
2 GB memory for Piano sounds |
|
|
All sounds can be replaced using Nord Sound Manager (Mac/Win) |
|
|
120 Voice Polyphony |
|
|
Categories |
Grand, Upright, Electric, Digital, Layer and Clav/Harpsichord |
|
3 Selectable Keyboard Touch Curves (Heavy, Medium, Light) |
|
|
Piano Timbre controls with custom settings for Electric Pianos and Clavinet |
|
|
String Resonance for acoustic Grand Pianos and Uprights |
|
|
Selectable Soft Piano Release |
|
|
Pedal Noise when used with Nord Triple Pedal 1, Nord Triple Pedal 2 or Nord Sustain Pedal 2 on selected acoustic and electric pianos |
|
|
Dynamic Compression |
|
|
Unison functionality |
|
|
2 Layers (2-Part Multitimbral) |
|
Synth Section |
Nord Wave 2 Synth Engine with Sample Playback |
|
|
Dedicated OLED Display for Waveform/Sample selection and parameter editing |
|
|
1 GB memory for Nord Sample Library |
|
|
All samples can be replaced using Nord Sound Manager (Mac/Win) |
|
|
46 Voice polyphony |
|
|
Oscillator Types |
Analog (incl. Super, Noise and Misc waveforms), Digital Waves, FM and Sample |
|
Analog Waveform options |
Pure, Shape, Shape Sine, Multi, Super, Sync, Bell, Misc (Noise) |
|
Classic Transistor Ladder Filter (LP M), 12 & 24 dB Low Pass, High Pass, Band Pass and combined Low Pass/Band Pass (LP+BP) filter |
|
|
Filter Drive |
Off, 1, 2 and 3 |
|
Filter Tracking |
Off, 1/3, 2/3 and Full |
|
3 Unison modes |
|
|
Vibrato modes controllable from Mod Wheel, Aftertouch and pedal. |
|
|
Filter envelope (Attack, Decay/Sustain, Release) with Velocity control |
|
|
Amplitude envelope (Attack, Decay/Sustain, Release) with Velocity control |
|
|
Oscillator envelope (Attack, Decay/Sustain, Release) with Velocity control |
|
|
LFO with 5 waveforms/modes: Square, Triangle, Ramp Dn, Ramp Up and Sample & Hold |
|
|
Advanced Arpeggiator with Arp, Polyphonic and Gate modes |
|
|
Arpeggiator Patterns for all modes, with Accent and Pan options |
|
|
LFO and Arpeggiator synchronizable to Master Clock |
|
|
3 Layers (3-Part Multitimbral) |
|
Effects |
Mod 1 |
remolo, Auto Pan, Ring Modulator, Wah-Wah, Auto-Wah, Pump (Sidechain modulation). Variation for each effect |
|
Mod 2 |
Phaser, Flanger, Vibe, Chorus, Ensemble, Spin. Variation for each effect |
|
Delay with Tempo, Feedback and Mix (Dry/Wet) controls, Ping Pong (stereo taps), Tap-Tempo, Feedback Filter (HP/LP/BP), Feedback Effects with Variations and panel selectable Analog mode. |
|
|
3 types of Amp/Speaker simulations |
Twin, JC and Small. Variation for each model |
|
Filter Mode (HP24/LP24) with Cut-off, Resonance and Mix controls |
|
|
Tube amp simulation with adjustable overdrive |
|
|
3-band Equalizer with sweepable mid. EQ ranges: 100 Hz, 200 Hz - 8 kHz and 4 kHz |
|
|
Rotary Speaker |
selectable speed (Stop, Slow and Fast) and separate overdrive |
|
Effect rates/tempo can be synchronized to the Master Clock |
|
|
Compressor with Fast Mode |
|
|
Reverb |
6 algorithms (Spring, Booth, Room, Stage, Hall and Cathedral) with Dark/Bright modes and Variation/Chorale options |
Keyboard |
|
|
|
Nord Stage 4 88 |
8-key Triple Sensor Hammer Action keyboard with Aftertouch. Range: A-C |
|
Nord Stage 4 73 |
73-key Triple Sensor Hammer Action keyboard with Aftertouch. Range: E-E |
|
Nord Stage 4 Compact |
73-key Triple Sensor Semi Weighted Waterfall keyboard with Aftertouch. Range: E-E |
Connections |
4 Assignable Audio Outputs |
¼", 6,35 mm jacks, unbalanced |
|
Stereo Headphone output |
¼", 6,35 mm stereo jack |
|
1 Monitor input |
1/8", 3,5 mm stereo jack |
|
Sustain Pedal |
¼", 6,35 mm jack. Compatible with Nord Sustain Pedal 2 (continuous sensor), Nord Triple Pedal 1 and switch type pedals |
|
Triple Pedal |
5 pin DIN connector. Compatible with Nord Triple Pedal 2 |
|
Rotor Pedal |
¼", 6,35 mm jack. Use a momentary pedal or a switch type pedal. |
|
Organ Swell Pedal |
¼", 6,35 mm TRS stereo jack |
|
Control Pedal |
¼", 6,35 mm TRS stereo jack. |
|
Foot Switch input |
¼", 6,35 mm jack. Use a momentary two-button pedal or a single switch type pedal. |
|
MIDI In |
5 pin DIN connectors |
|
MIDI Out |
5 pin DIN connectors |
|
USB |
type B connector for USB MIDI, Software Update and Sound Transfer |
|
Power Cord with IEC C14 connector |
|
Included Accessories |
Single Pedal 1 included with Stage 4 73 and 88 |
|
|
User Manual |
|
|
Power cord |
|
|
USB cord |
|
Dimensions |
Nord Stage 4 88 |
1282 mm (50.5"), 121 mm (4.7"), 349 mm (13.7") |
|
Nord Stage 4 73 |
1069 mm (42"), 121 mm (4.7"), 349 mm (13.7") |
|
Nord Stage 4 Compact |
1066 mm (42"), 104 mm (4,1"), 322 mm (12.7") |
Weight |
Nord Stage 4 88 |
19.6 kg (43.2 lb) |
|
Nord Stage 4 73 |
16.7 kg (36.8 |
|
Nord Stage 4 Compact |
10.4 kg (22.9 lb) |
