General |
Dual Piano and Dual Synth Layers |
|
|
OLED Display |
|
|
Seamless Transitions |
|
|
Split Point Crossfades |
|
|
16 banks with 36 programs - 576 locations |
|
|
Organize for programs |
|
|
Organize for programs |
|
|
Live Mode |
6 Live programs |
|
Global Transpose |
+/- 6 semitones |
|
Global Fine-tune |
+/- 50 Cents |
|
Program Transpose |
+/- 6 semitones |
|
88 or 73-note Triple Sensor keybed with grand weighted action |
|
|
Selectable split point with LED indication (9 locations) |
|
|
Nord Triple Pedal 2 included |
|
|
MIDI over USB |
|
Piano Section |
2 independent Layers |
|
|
2 GB memory for Piano sounds |
|
|
All sounds can be replaced using Nord Sound Manager (Mac/Win) |
|
|
120 Voice Polyphony |
|
|
Categories |
Grand, Upright, Electric, Digital/Layer, Clav/Harpsichord and Misc |
|
3 Selectable Keyboard Touch Curves (Heavy, Medium, Light) |
|
|
Piano Timbre controls with custom settings for Electric Pianos and Clavinet |
|
|
String Resonance for acoustic Grand Pianos and Uprights |
|
|
Pedal Noise when used with Nord Triple Pedal 1, Nord Triple Pedal 2 or Nord Single Pedal 2 on acoustic and electric pianos |
|
|
Dynamic Compression |
|
|
Unison functionality |
|
Sample Synth Section |
2 independent Layers |
|
|
1 GB memory for Nord Sample Library |
|
|
Amp envelope with Attack, Decay/Sustain and Release controls |
|
|
Vibrato with Rate/Amount, Delay, button or pedal |
|
|
Unison with 3 amounts |
|
|
Mono, Legato and Glide |
|
|
Octave transpose |
-1/+1 (-6/+6 in Split mode, depending on Split position) |
Effects Section |
Mod 1 |
Tremolo, Pan 1 (Soft), Pan 2 (Hard), Spin, Wah, Ring Modulator (controllable via optional pedal) |
|
Mod 2 |
Phaser 1, Phaser 2, Flanger, Chorus 1, Chorus 2, Vibe, Spin. Stereo/Mono options for each effect |
|
Equalizer |
Per Layer or Global, 3-band with sweepable mid (200 Hz - 8 kHz) |
|
Amp |
Twin, JC and Small. Each with Alternate Tone option |
|
Compressor |
Per Layer or Global, Amount control |
|
Delay |
Per Layer or Global, Tempo, Feedback and Mix (Dry/Wet) controls, Ping Pong with 3 amount options, Tap-Tempo, Feedback Filter (HP/LP/BP), Flam |
|
Reverb |
Global Reverb with Dry Wet amount optionally controllable per Layer. Spring, Booth, Room, Stage, Hall and Cathedral Reverb types, each with optional Pre-Delay, Chorale and Bright/Dark modes. |
|
Group mode for Effects |
|
Connections |
2 Audio outputs L & R |
¼", 6,35 mm jacks, unbalanced |
|
1 Monitor input |
1/8", 3,5 mm stereo jack |
|
1 Headphone output |
¼", 6,35 mm stereo jack |
|
1 Sustain Pedal input |
¼", 6,35 mm jack. Compatible with Nord Triple Pedal or a momentary pedal |
|
Triple Pedal |
5 pin DIN connector. Use the included Nord Triple Pedal 2 |
|
1 Control/Volume Pedal input |
¼", 6,35 mm TRS stereo jack. |
|
MIDI In, MIDI Out |
5 pin DIN connectors |
|
USB |
type B connector - for transferring sounds and USB MIDI |
|
IEC C14 power connector |
|
Dimensions |
Nord Piano 6 88 |
1282 mm (50.5"), 121 mm (4.7"), 349 mm (13.7") |
|
Nord Piano 6 73 |
1069 mm (42"), 121 mm (4.7"), 349 mm (13.7") |
Weight |
Nord Piano 6 88 |
19.2 kg (42.3 lbs) |
|
Nord Piano 6 73 |
16.2 kg (35.7 lbs) |
Included Accessories |
Nord Triple Pedal 2 |
|
|
User Manual |
|
|
Power cord |
|
|
Dust Cover |
|
